696 ZZ Miniature Deep Groove Ball Bearing
The 696 ZZ Miniature Deep Groove Ball Bearing is small and suitable for installation on thin shafts where space is limited. It can withstand very high speeds. Main dimensions according to DIN 625-1.
696 ZZ is made of bearing steel, which is durable and can withstand heavy loads. The bearing is sealed on both sides to save grease and prevent impurities from entering, suitable for complex environments, pre-lubricated, and easy to maintain.
Main Applications of the 696 ZZ Miniature Deep Groove Ball Bearing
Element and single row deep groove ball bearings have a wide range of applications, are simple in design, cannot be separated, are suitable for high speeds, operate robustly and require little maintenance. The deep raceway grooves and the tight fit between the raceway grooves and the balls enable deep groove ball bearings to withstand axial loads as well as radial loads in both directions.
The 696 ZZ Miniature Deep Groove Ball Bearing is highly versatile and widely used across various industries due to its compact size and reliable performance. Common applications include small electric motors, precision measuring instruments, medical equipment, and modern household appliances. Because it can handle high rotational speeds and moderate radial loads, it is also a preferred choice for 3D printers, RC hobbies (such as remote-controlled cars and helicopters), and advanced robotics. If you are manufacturing handheld power tools or office automation equipment, this exact 6x15x5mm bearing offers the perfect balance of durability, low friction, and operational efficiency.
Material Specifications and Durability
Manufactured from high-grade chrome steel (or premium stainless steel, depending on your specific environmental requirements), this bearing ensures an exceptionally long service life, even under demanding operational conditions. The “ZZ” designation in the model number indicates that the 696-ZZ Miniature Deep Groove Ball Bearing is shielded on both sides with metal dust covers. These double shields are absolutely crucial for keeping factory-applied lubricants safely inside the bearing track while effectively preventing the ingress of dust, dirt, moisture, and other microscopic contaminants. This self-contained, protected environment significantly reduces long-term maintenance costs and unexpected downtime for your machinery.
Why Choose Our Professional OEM Solutions?
When sourcing miniature bearings for your assembly or production line, batch-to-batch consistency is key. Our advanced manufacturing process guarantees strict tolerance levels, ensuring every single 696 ZZ Miniature Deep Groove Ball Bearing you receive strictly meets international quality standards for noise reduction, vibration control, and dimensional accuracy. Whether you need a standard wholesale batch or require custom lubrication and internal clearance settings for extreme temperatures, our experienced engineering team is ready to provide tailored OEM solutions to fit your exact mechanical requirements.
● Small diameter sizes are available
● Suitable for high speed rotation.
● Sealed ball bearings with grease.
● High temperature resistance
Click here and download the data sheet of 696 ZZ deep groove ball bearings or contact us and get more detailed information.
For any inquiries, please contact with our Supporting Team at sales@yuanhecd.com.
| Model | 696 ZZ |
| Item | Miniature Ball Bearings |
| Type | Shielded |
| Bore Dia (d). | 6 mm |
| Outside Dia (D). | 15 mm |
| Width (B) | 5 mm |
| ABEC Tolerance | 3 |
| Dynamic Load Capacity (kN) | 1.35kN |
| Static Load Capacity (kN) | 0.53kN |
| Max. RPM | 44,000RPM |
| Temp. Range (℃) | -40~120℃ |
| Material | Steel |
| Shield Material | (SPCC) Mild steel ( SPCC) |
| Lubrication | Grease |
696 ZZ deep groove ball bearings are made of bearing steel for durability and resistance to rust, corrosion and deformation, and guards on both sides prevent lubricant ingress and contamination. They can withstand radial and axial loads.
This type of bearing is suitable for all kinds of industrial equipment, agricultural machinery, conveying equipment, robots, dental equipment, elevator micromotors, small rotating motors, office equipment, etc.
Yuanhe deep groove ball bearings have low friction, high maximum speed, cost-effective and almost no maintenance. If you have any questions or concerns about the product, please contact us!
Other types of ball bearings are also available: 6903 ZZ, 6903 2RS, 6901 ZZ, 6900 ZZ, 6809 ZZ, 6809 2RS. If you’re interested in our procucts, please feel free to contact us.
